Flush Floor Box - Deep Recessed Stainless Steel

CAT NO. FB2SDR70

Capacity:

2 x single auto switched power outlets
and 3 x data mounts

Box Size:

250 x 160 x 93mm Deep (c/w-Lid)

Lid Material:

Stainless 304 – No. 4 Linished

Lid Recess:

20mm Deep

Suitable for:

Cat6A and Cat7A Cabling

Key Features

  • Recessed Stainless Steel Lid and Frame with 20mm rebate for floor finish (typically polished timber boards or ceramic tiles).
  • 304 Grade solid Stainless Steel lid construction with No. 4 Linished finish.
  • Adjustable Soft Closer to control lid closure – suits floor finish infills up to 2kg    (eg. timber packer & carpet, full timber, ceramic tile or stone).
  • Frame has square edges (not bevelled) to allow flush fitting to adjacent              floor finish.
  • Height adjustable lid and frame.
  • Robust, large capacity cable exit flap with CableShield and stainless lifting handle.
  • Option to fit cam lock if required.
  • Capacity for 2 x single auto switched power outlets (supplied) and 3 x data mounts.
  • Suitable for category 6A and 7A data cabling with generous bend radius capacity.
  • Suitable for Audio / Video outlets including VGA, HDMI, USB, etc.
  • Modular box body and lid design, interchangeable with plastic and other lids in the ECD® floor box range.
