PROTECTOR™ SERIES HEAVY DUTY Flush Floor Box, Flush, Square Edged, Stainless Steel

CAT NO. FB1SHD

Features:

Load rated with Cable Shield® suitable for vehicle traffic

Capacity:

1 standard size GPO and 1 No. 3 Gang Data Plate

Box Size:

150 x 150 x 115 mm Deep

Lid Material:

Stainless 304 – No. 4 Linished

Suitable for:

Compact installations

Key Features

  • Heavy duty – load rated floor box suitable for vehicular traffic.
  • Ideal for car showrooms and shopping centres.
  • Flush Protector™ Series Stainless Steel lid and frame with No. 4 Linished finish.
  • Protector™ Series features Cable Shield® Frame assembly to prevent cables being cut. (Patent Certified 2017100897 & Patent Pending 2015204344)
  • Frame has square edges (not bevelled) to allow flush fitting to adjacent floor finish (typically timber, tiles or vinyl).
  • Robust and large capacity cable exit flap with retracing lifting handle.
  • Capacity for 1 x standard D/GPO and 3 x Data.
  • Supplied with temporary construction lid.
  • This product has been examined in accordance with AS 3000 and conforms to A.C.M.A. requirements.
