Stainless Steel Floor Box - Heavy Duty 12mm Deep Recess

CAT NO. FB149HD

Features:

Load rated suitable for vehicle traffic

Capacity:

1 standard size GPO
1 No. 3 Gang Data Plate

Box Size:

150 x 150 x 120 mm Deep

Lid Material:

Stainless Steel

Lid Rebate:

12 mm Deep

Suitable for:

Compact Installations

Key Features

  • Heavy duty – load rated floor box suitable for vehicular traffic.
  • Ideal for car showrooms and shopping centres.
  • 304 Grade Stainless Steel lid construction with No. 4 Linished finish.
  • 12mm rebate for floor finish (typically timber boards or ceramic tiles).
  • Frame has square edges (not bevelled) to allow flush fitting to adjacent floor finish.
  • Robust, large cable exit flap and stainless steel lifting handle.
  • Capacity 1 x standard double GPO and 3 x Data (grid plate supplied).
  • Supplied with temporary construction lid.
  • This product has been examined in accordance with AS 3000 and conforms to A.C.M.A. requirements.
