Round Flush Floor Box Recessed, Stainless Steel
CAT NO. FB599
| Capacity: | 6 standard sized plates |
| Box Size | 350 x 350 x 115 mm Deep |
| Lid Surface Size: | 325 mm Diameter |
| Features: | Cable Shield® Frame |
| Lid Material: | Stainless 304 – No. 4 Linished |
| Lid Rebate: | 6mm Deep |
| Suitable for: | Cat6A & 7A Cabling |
Key Features
- Recessed Protector™ Series Stainless Steel Lid and Frame 6 mm rebate for floor finish (typically carpet or vinyl).
- Protector™ Series features
- Cable Shield® Frame assembly to prevent cables being cut. (Patent Certified 2017100897 & Patent Pending 2015204344)
- Soft close lid to stop lid from slamming shut
- Cable retainer for easy cable management. Robust and large capacity cable exit flap with stainless lifting handle.
- Robust and large capacity cable exit flap with stainless lifting handle.
- Capacity for 6 standard outlet plates (typically 4 x double power and 2 x data, but this can be reversed).
- Suitable for Audio/Video outlets including VGA, HDMI, USB etc.
- Suitable for category 6A and 7A data cabling with generous bend radius capacity.
- Suitable for Audio/Video outlets including VGA, HDMI, USB, etc.
- 304 Grade solid Stainless Steel lid with No. 4 Linished finish.
- Option to fit cam lock if required.
- This product has been examined in accordance with AS 3000 and conforms to A.C.M.A. requirements.
* Click images to enlarge
