PROTECTOR™ SERIES Flush Floor Box - Flush, Stainless Steel
CAT NO. POPULAR – FB6SF
| Capacity: | 6 standard sized plates |
| Box Size: | 360 x 240 x 110mm deep |
| Features: | • Cable Shield® Frame |
| Lid Material: | Stainless 304 – No. 4 Linished |
| Suitable for: | Cat6A & 7A Cabling |
| Load Rating: | 120kg (per foot = foot traffic) |
Key Features
- Flush Protector™ Series stainless steel lid and frame with No. 4 Linished finish.
- Protector™ Series features
- Cable Shield® Frame assembly to prevent cables being cut. (Patent Certified 2017100897 & Patent Pending 2015204344)
- Soft close lid to stop lid from slamming shut
- Cable retainer for easy cable management.
- Robust and large capacity cable exit flap with stainless steel lifting handle.
- Suitable for umbilical connection at cable exit flap location.
- Capacity for 6 standard outlet plates (3 x double power and 3 x data and/or A.V.).
- Suitable for category 6A and 7A data cabling with generous bend radius capacity.
- Suitable for Audio / Video outlets including VGA, HDMI, USB, etc.
- 304 Grade solid stainless steel with No. 4 Linished finish to meet P1 requirements for slip resistance in public spaces (dry areas).
- Modular box body and lid design, interchangeable with plastic and other lids in the ECD® floor box range.
- Supplied with temporary construction lid.
- Option for factory fitted cam lock if required.
* Click images to enlarge
